All In One ESS 51.2V Lithium Battery With Inverter 20kwh 30kwh

Place of Origin GUANGDONG,CHINA
Brand Name GUOAN
Certification CE/ UL/ UN38.3/ Ect.
Model Number GA-Y5KW
Price Negotiable
Packaging Details Wooden pallets, cartons, foam, plastic wrap,ect. You can also customize it.
Delivery Time 7-30 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union
Supply Ability Semi-automated Custom Manufacturer

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Energy Storage Battery With Inverter Voltage 51.2V/Custom
Power 5KW Battery Type LiFePO4 Battery
Quality Long Life Batteries,All In One,ect. Cycle Life 6000 Times
BMS Protection Built-in OEM/ODM Accepatable Custom
High Light

51.2V Lithium Battery With Inverter

,

Lithium Battery With Inverter 20kwh

,

5KW Lithium Battery LifePO4

Leave a Message
Product Description

Factory Home Appliance 51.2V 5Kw Lifepo4 Storage Battery All In One Solar Power

The household 5kW LiFePO4 all-in-one battery is a complete energy storage solution designed for residential and commercial use. Its LiFePO4 chemistry, integrated design, and hybrid three-phase inverter make it a versatile and efficient energy storage solution. Additionally, its multiple safety features and environmentally friendly design make it a safe and sustainable choice for energy storage.





FEATURES



▶ High efficiency: The LiFePO4 chemistry used in the battery pack has a high energy density, which means it can store a large amount of energy in a compact size.


▶ Long cycle life: LiFePO4 chemistry is known for its long cycle life, which means the battery pack can be charged and discharged many times without significant degradation.


▶ Safe: The battery pack includes multiple safety features, which help prevent damage to the battery and ensure safe operation.


▶ Integrated design: The battery pack and hybrid inverter are integrated into a single unit, which simplifies installation and operation.


▶ Environmentally friendly: The battery pack allows users to maximize their use of renewable energy sources, reducing their reliance on non-renewable energy sources and reducing their carbon footprint.





SPECIFICATIONS

Nominal Parameters
Battery Type
LiFePO4
Rated Voltage
51.2V
Rated Capacity
100Ah
Rated Energy
5.23KWH
Rated Power
5KW
Max continouse charging current
100A
Dimensions(L×W×H)
540*535*463mm


ENERGY STORAGE BATTERY

Battery cell
LifePO4 3.2V 200ah
Voltage out of factory
47.8V-49.8V(40-60%)
Cycle life
6000cycles ≥ 80%
Min Cut-off Voltage
40V
Standard charing voltage
58.4V
Inner resistance
≤50mΩ
Standard charging current
0.2C/40A
Standard discharging current
0.2C/40A
Protective functions
over-charing/over-discharging/over-heat/shortcurcuit
Communication port
RS485/CAN/RS232
Working tempreture
Charge(charging):0~60℃
Discharge(charging):-20~60℃



INVERTER

Inverters Rated Power
4KW
5KW
6KW
8KW
10KW
12KW
Maximum PV Charge Current
80A
80A
80A
120A
120A
120A
Maximum PV Array Power
5000W
5000W
5000W
7000W
7000W
7000W
Overcharger Protection

AMG:60V; FLD:62V; USE:CV+4.0V


Maximum Charge Current
40A
50A
60A
70A
80A
100A
Maximum Charge Current (PV+AC)
120A
130A
140A
180A
180A
180A
Net Weight (Solar CHG)
38kg
41kg
45kg
64kg
66kg
75kg
Typical Transfer Time
10ms
10ms
10ms
10ms
10ms
10ms
inverters AC Input Voltage
104V-110V-115V-120VAC/ 208V-220V-230V-240VAC Optional
Monitoring Option
WIFI or GPRS
Output Frequency
50Hz/60Hz ±0.1Hz
MPPT Operating Voltage
60-145VDC
Maximum PV Array Open
Circuit Voltage
150VDC





FUNCTION

All In One ESS 51.2V Lithium Battery With Inverter 20kwh 30kwh 0

Energy Storage With Inverter



The battery pack stores energy for use during periods of high demand or when the main power source is unavailable.











All In One ESS 51.2V Lithium Battery With Inverter 20kwh 30kwh 1

Communication Port



The battery pack can be used to shift energy consumption to off-peak periods, reducing energy costs.You can also custom them,pls contact us.

All In One ESS 51.2V Lithium Battery With Inverter 20kwh 30kwh 2





Backup Power



The battery pack provides backup power in the event of a power outage or other emergency situations.

All In One ESS 51.2V Lithium Battery With Inverter 20kwh 30kwh 3

Solar Energy Storage System



You can also choose to customize a complete solar energy storage system for your home office and other places





APPLICATIONS



This energy storage system is ideal for a wide range of residential and commercial applications, including:

● Backup power systems for homes or businesses
● Energy storage systems for renewable energy systems, such as solar or wind power
● Grid-tied energy storage systems for reducing electricity bills and peak demand charges
● Off-grid energy storage systems for remote locations

● Remote cabins or vacation homes
● Emergency backup power for homes in areas with frequent power outages
● Sustainable living in areas without access to the grid

All In One ESS 51.2V Lithium Battery With Inverter 20kwh 30kwh 4





CUSTOM FACTORY



We are a customized manufacturer, with a professional R & D design team and automated production lines.

We support one-to-one customization and can give you a satisfactory design according to the use.



All In One ESS 51.2V Lithium Battery With Inverter 20kwh 30kwh 5
